BROWN & SHARPE Micromaster Surface Grinders Parts Manual

This is a reproduction, not a photocopy, of an original Brown & Sharpe Repair Parts Manual for the 824, 1024, 1030, 1224, and 1236 Micromaster Surface Grinding Machines. This manual contains contains exploded parts views of the parts. Please read contents below.

824

Contents:

Antifriction Bearing Spindle with Direct Drive.............................................	8-9
Antifriction Bearing Spindle with Oriflex Drive............................................	6-7
Automatic Slot Grinding to Positive Stop...................................................	44-45
Automatic Slot or Surface Grinding to Positive Stop...................................	48-49
Automatic Surface Grinding to Positive Stop..............................................	46-47
Cross Feed Cylinder.................................................................................	26-27
Cross Feed Handwheel Complete.............................................................	22-23
.0001" Cross Feed Handwheel Complete..................................................	62-63
Cross Feed Screw....................................................................................	24-25
Cycle-Size Arrangement............................................................................	52-61
Electrical Control Panel.............................................................................	42
Elevating Handwheel Complete.................................................................	10-11
Elevating Screw........................................................................................	14-15
Elevating Shaft and Drive..........................................................................	12-13
Front View...............................................................................................	40-41
Hydraulic and Lubrication Pumps, Piping, etc.............................................	36-39
Hydraulic Control Panel and Valve............................................................	32-35
Hydraulic and Electrical Controls...............................................................	74-75
Index Centers...........................................................................................	43
Lubrication Schematic Diagram.................................................................	70-71
Over The Wheel Truing Attachment...........................................................	50-51
Power Down Feed....................................................................................	66-69
Power Truing Attachment..........................................................................	76-77
Radius and Angle Wheel Truing Attachment...............................................	76-77
Rear View.................................................................................................	5
Start and Stop Control Box.......................................................................	30-31
Table Handwheel Complete.......................................................................	16-17
Table Cylinder, Dogs, Racks and Guards...................................................	18-19
Table Reversing Lever and Connector.......................................................	20-21
Upright......................................................................................................	28-29
Vertical Position Indicator..........................................................................	64-65
Wet Grinding Attachment..........................................................................	72-73

Overview:

I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear.
