Number of Pages: 44
This is a reproduction of an original Unimat Miniature Machine Techiques Manual. This covers the Unimat-SL pictured below.
Contents: Abrasive Discs | 39 | Adapter Stud | 6,21 | Adjusting Motor Bracket | 8 | Aligning Spindle | 13 | Backlash Adjustment | 13 | Belts | 6,8,9,31 | Boring | 19 | Buffing | 35 | Chucks, Drill | 15,37 | 3-Jaw | 25,26 | 4-Jaw, Mounting | 16,26 | Collet, Mounting | 27 | Circular Saw Attachment | 40 | Cleaning and Oiling | 27,42 | Collets | 27,36 | Countersinking Work pieces | 22,23 | Cutting Lubricant | 18,22 | Drawbar Lathe Spindle | 36 | Type WW Accessories | 37 | Dressing Grinding Wheels | 35 | Drilling | 18,22 | Deep-Hole Drilling | 18,22 | Horizontal | 18 | Sensitive Drilling | 23 | Faceplate Turning | 16 | Facing | 13 | Finishing | 18 | Flexible Shaft | 35 | Grinding Wheels | 35 | Wheel Guard | 35 | Wheel Arbor | 35 | Guarantee | 13 | Handwheel Calibration | 18 | Horizontal Drilling and Reaming | 33 | Indexing and Dividing Head | 39 | | Jigsaw Attachment | 39 | | Lathe Dog | 11,13 | | Live Centers | 25,28 | | Lubricating Spindle | 42 | | Maintenance | 4200 |
Overview
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
|
