KEARNEY TRECKER SI-61, S-12 Mill Installation Manual

Price:

$25.00

Availability:

In Stock

Manual Description

Number of Pages: 20

This is a reproduction of an original Kearney Trecker SI-61 Milling Machine Installation Manual with S-12 knee types.

Contents:

Uncrating.......................................9
Shortages.......................................9
Hoisting........................................9
Cleaning.......................................10
Location.......................................10
Leveling the Machine...........................10
Table Assembly.................................11
Table Bracket Left Hand........................12
Thrust Bearing Adjustment......................12
Table Bracket Right Hand.......................13
Thrust Bearing Adjustment Check................13
Electrical Connections.........................14
Pulley Belt Adjustment.........................14
Gib Adjustments................................14
Lubrication Instructions
Plain and Universal............................15
Vertical and Ram...............................16
Machine Dimensions
Plain, Universal and Vertical..................17
Ram Head.......................................18
Plan Dimensions................................19

Kearney Trecker

Overview

I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
